Fire-Rated Glass Solutions by Bear Glass

Fire rated glass is ideal for cases where one needs open space and natural light in abundance, and the proper fire rating of the establishment. Our clients can use such glass in both external and internal applications.

PRODUCT

Fire-Rated Glass

Fire-rated glass is a type of safety glass designed to resist the spread of fire and smoke for a specified period. It is made using specialized materials and manufacturing processes that enhance its thermal resistance and structural integrity when exposed to high temperatures. Fire-rated glass is commonly used in buildings where fire safety is a critical concern, such as in doors, windows, partitions, and facades. By containing the spread of fire, it helps protect occupants and allows more time for evacuation and firefighting efforts. Additionally, it maintains visibility and natural light, making it a practical solution for modern architecture while ensuring compliance with fire safety regulations.

Need Fire-Rated Glass?

Consult with our experts to know what is best for you.

Request a Quote

Our Fire-rated Glass Products

Bear Glass Carries The Best in Quality Fire-Rated Glass

Fire rated glass is ideal for cases where one needs open space and natural light in abundance, and the proper fire rating of the establishment. Our clients can use such glass in both external and internal applications.

These products are available in various fire-ratings that are designed to cater to most of the glazing classifications and applications as per your requirements.

3/16" PYRAN® PLATINUM

FIRE RATING: 20 - 90 Min.

PYRAN® Platinum fire-protection rated glazing material is made from a transparent glass-ceramic with a thickness of 3/16” (5mm). It is intended for use in non-impact, non-safety rated locations such as transoms and windows with a true-color rendition and fire-rating requirements up to 90 minutes.

SAFETY
  • Fire-rated for up to 90 minutes with required hose-stream test
  • Passes positive pressure test standard UL 10C
  • Withstands thermal shock
Where can it be Used?
  • Can be used to construct insulated glazing units
  • Can be lightly sandblasted or delivered with surface-applied opacity film, without affecting fire rating
  • Approved for use with any standard fire-rated frame with same rating

3/16" PYRAN® PLATINUM F

FIRE RATING: 20 - 180 Min.

PYRAN® Platinum F is a fire-protection rated and impact safety-rated glazing material that is made from a transparent glass-ceramic with a thickness of 3/16" (5mm). It has a surface applied safety film and is intended for use in safety-rated locations such as door lites, transoms or sidelites, and windows with fire-rating requirements up to 90 minutes, and up to 180 minutes in doors.

SAFETY
  • Surfaced-applied safety film, impact safety-rated: meets ANSI Z97. 1 and CPSC 16CFR1201 (Cat. I and/or II)
  • Fire-rated for up to 90 minutes with required hose-stream test
  • Fire-rated for up to 180 minutes in doors with required hose-stream test
  • Withstands thermal shock
  • Passes positive pressure test standard UL 10C
Where can it be Used?
  • Can be used to construct insulated glazing units
  • Can be lightly sandblasted or delivered with surface-applied opacity film, without affecting fire rating
  • Approved for use with any standard fire-rated frame with same rating

5/16" PYRAN® PLATINUM L

FIRE RATING: 20 - 180 Min.

PYRAN® Platinum L is a fire-protection-rated and impact-safety-rated glazing material with a thickness of approximately 5/16”, made from a laminated glass-ceramic with a transparent appearance. It is intended for use in safety-rated locations such as door lites, transoms or sidelites, and windows with fire-rating requirements up to 90 minutes, and up to 180 minutes in doors.

SAFETY
  • Laminated floated glass-ceramic, impact safety-rated: meets ANSI Z97. 1 and CPSC 16CFR1201 (Cat. I and/or II)
  • Fire-rated for up to 90 minutes with required hose-stream test
  • Fire-rated for up to 180 minutes in doors with required hose-stream test
  • Withstands thermal shock
  • Passes positive pressure test standard UL 10C
Where can it be Used?
  • Can be used to construct insulated glazing units
  • Can be lightly sandblasted or modified with surface-applied decorative or opacity films without affecting the fire rating or UL listing

BEAR GLASS

Fire-Protective Glazing: Enhancing Safety in Buildings

Fire-protective glazing is a specialized type of glass designed to resist the spread of fire and smoke, providing crucial time for evacuation and firefighting efforts. Here's a closer look at its benefits and applications:

Benefits of Fire-Protective Glazing:
  • Fire Resistance: Withstands high temperatures and prevents the spread of flames and hot gases.
  • Smoke Containment: Limits the passage of smoke, reducing visibility hazards and toxic gas exposure.
  • Thermal Insulation: Minimizes heat transfer, protecting adjacent areas from radiant heat.
  • Impact Resistance: Many fire-protective glazing solutions also offer impact resistance, enhancing safety from both fire and physical hazards.

By integrating fire-protective glazing into building designs, architects and builders can enhance safety while maintaining aesthetic and functional requirements. This technology plays a vital role in modern fire safety strategies, protecting both people and property. Regular inspection and maintenance are crucial to ensure the glazing's performance over time.

Always Ensure the glazing meets the required fire rating for the specific application. Look for products certified by recognized testing standards. Fire-rated glass is durable but regular inspection and maintenance are crucial to ensure the glazing's performance over time.

AREA OF USE

Applications of Fire-Protective Glazing

By integrating fire-protective glazing into building designs, architects and builders can enhance safety while maintaining aesthetic and functional requirements. There are many areas we can integrate fire-rated glass.

  • Doors and Windows: Installed in fire-rated doors and windows to maintain compartmentalization.
  • Partitions and Wall: Used in interior partitions and walls to create fire-resistant barriers.
  • Thermal Insulation: Minimizes heat transfer, protecting adjacent areas from radiant heat.
  • Facades and Atriums: Incorporated into building facades and atriums for both aesthetic and safety purposes.
  • Stairwells and Corridors: Essential in escape routes to ensure safe evacuation paths.

When selecting fire-protective glazing, it's crucial to ensure that the product meets the required fire rating for the specific application. This involves verifying that the glazing has been tested and certified to withstand exposure to fire for a specified duration, such as 30 minutes, 60 minutes, or more, depending on the building codes and regulations.

Don't just stop at fire rating – make sure your glazing product has the certifications and compliance credentials to match. And remember, a little maintenance goes a long way! Regular check-ups will keep your glazing in top shape, ensuring it continues to perform when it matters most.

Fire-Rated Glass Specifications

Glass Types PYRAN® PLATINUM, PYRAN® PLATINUM F, PYRAN® PLATINUM L
Fire Rating 20 - 90 Min., 20 - 180 Min
Glass Thickness 3/16", 5/16"
Customization Can be lightly sandblasted
impact safety-rating meets ANSI Z97.1 and CPSC 16CFR1201 (Cat. I and/or II)

Request a Quote

To know more about our product and to get a no obligation quote, Please fill the form below and we will get back to you soon.

Please give your Full Name.
Please enter your Country Name.
Please give your Email Address.
Please give your Phone Number.
Please give the Service you need.
Please enter the Message.

Frequently Asked Questions

Fire-rated glass is a type of safety glass designed to resist the spread of fire and smoke for a specified period, providing protection and time for evacuation.

Fire-rated glass is made using specialized materials and manufacturing processes that enhance its thermal resistance and structural integrity when exposed to high temperatures, preventing the spread of flames and hot gases.

Fire-rated glass provides numerous benefits, including enhanced safety, reduced risk of injury and property damage, compliance with building codes and regulations, and preservation of natural light and visibility.

Fire-rated glass is commonly used in buildings where fire safety is a critical concern, such as in doors, windows, partitions, facades, stairwells, and corridors.

There are several types of fire-rated glass, including tempered glass, laminated glass, and ceramic glass, each with its own unique characteristics and benefits.

Fire-rated glass undergoes rigorous testing to evaluate its performance in terms of fire resistance, thermal shock resistance, and impact resistance, among other factors.

Fire-rated glass is specifically designed to withstand exposure to fire and high temperatures, whereas regular glass can shatter or melt when exposed to heat, compromising safety and security.

Yes, fire-rated glass can be customized to meet specific design and functional requirements, including various sizes, shapes, and frame styles.

Fire-rated glass requires regular inspection and maintenance to ensure its performance and safety over time, including cleaning, checking for damage, and replacing damaged or compromised glass.

While fire-rated glass may be more expensive than regular glass, its benefits in terms of safety, security, and compliance with building codes and regulations make it a valuable investment for building owners and occupants.
